Image based on a complex. More...
#include <complex_image.hh>
Public Types | |
| typedef p_complex< D, G > ::bkd_piter | bkd_piter |
| Backward Site_Iterator associated type. | |
| typedef Image< void > | category |
| typedef p_complex< D, G > | domain_t |
| Site_Set associated type. | |
| typedef complex_image< D, G, V > | exact_t |
| typedef p_complex< D, G > ::fwd_piter | fwd_piter |
| Forward Site_Iterator associated type. | |
| typedef G | geom |
| The geometry type of the complex. | |
| typedef V & | lvalue |
| Return type of read-write access. | |
| typedef fwd_piter | piter |
| Site_Iterator associated type; default definition is fwd_piter. | |
| typedef p_complex< D, G >::psite | psite |
| Point_Site associated type. | |
| typedef const V & | rvalue |
| Return type of read-only access. | |
| typedef p_complex< D, G >::site | site |
| Site associated type. | |
| typedef complex_image< D, tag::psite_< G >, tag::value_ < V > > | skeleton |
| Skeleton. | |
| typedef mln::value::set< V > | t_eligible_values_set |
| Eligible-value-set associated type. | |
| typedef mln::value::set < typename mln::value::super_value< V > ::ret > | t_values_space |
| Value space associated type. | |
| typedef V | value |
| Value associated type. | |
Public Member Functions | |
| void | destroy () |
| Detach data from an image (free it if nobody else hold it). | |
| bool | has (const psite &p) const |
Test if p belongs to the image domain. | |
| const util::tracked_ptr < internal::data < complex_image< D, G, V > > > & | hook_data_ () const |
| Hook to the image data. | |
| const void * | id_ () const |
| Give an identifier of this image. | |
| unsigned | index_of_point (const P &p) const |
Give the offset of the site p. | |
| void | init_ (const p_complex< D, G > &pc, const metal::vec< D+1, std::vector< V > > &values) |
| Initialize an empty image. | |
| bool | is_valid () const |
| Test if this image has been initialized; default impl. | |
| std::size_t | nsites () const |
| Give the number of sites of the image domain. | |
| lvalue | operator() (const complex_psite< D, G > &p) |
Read-write access of face value at point site p. | |
| rvalue | operator() (const complex_psite< D, G > &p) const |
Read-only access of face value at point site p. | |
| const t_eligible_values_set & | values_eligible () const |
| const t_values_space & | values_space () const |
| Return the value space of the image. | |
| complex_image () | |
| Constructors. | |
| complex_image (const p_complex< D, G > &pc) | |
| complex_image (const p_complex< D, G > &pc, const metal::vec< D+1, std::vector< V > > &values) | |
| const p_complex< D, G > & | domain () const |
| Accessors. | |
| const metal::vec< D+1, std::vector< mlc_unbool(V) > > & | values () const |
| Return the array of values associated to the faces. | |
Static Public Attributes | |
| static const unsigned | dim = D |
| The dimension of the complex. | |
Protected Attributes | |
| util::tracked_ptr < internal::data < complex_image< D, G, V > > > | data_ |
Detailed Description
template<unsigned D, typename G, typename V>
class mln::complex_image< D, G, V >
Image based on a complex.
Values attached to each face of the complex.
- Template Parameters:
-
D The dimension of the complex. G The geometry type of the complex. V The value type of the image.
Definition at line 164 of file mln/core/image/complex_image.hh.
Member Typedef Documentation
typedef p_complex< D, G > ::bkd_piter mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::bkd_piter [inherited] |
Backward Site_Iterator associated type.
Definition at line 118 of file core/internal/image_base.hh.
typedef Image<void> mln::Image< complex_image< D, G, V > >::category [inherited] |
Reimplemented from mln::Object< complex_image< D, G, V > >.
Definition at line 75 of file core/concept/image.hh.
typedef p_complex< D, G > mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::domain_t [inherited] |
Site_Set associated type.
Definition at line 105 of file core/internal/image_base.hh.
typedef complex_image< D, G, V > mln::Object< complex_image< D, G, V > >::exact_t [inherited] |
typedef p_complex< D, G > ::fwd_piter mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::fwd_piter [inherited] |
Forward Site_Iterator associated type.
Definition at line 115 of file core/internal/image_base.hh.
| typedef G mln::complex_image< D, G, V >::geom |
The geometry type of the complex.
Definition at line 172 of file mln/core/image/complex_image.hh.
| typedef V& mln::complex_image< D, G, V >::lvalue |
Return type of read-write access.
Definition at line 177 of file mln/core/image/complex_image.hh.
typedef fwd_piter mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::piter [inherited] |
Site_Iterator associated type; default definition is fwd_piter.
Definition at line 123 of file core/internal/image_base.hh.
typedef p_complex< D, G > ::psite mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::psite [inherited] |
Point_Site associated type.
Definition at line 108 of file core/internal/image_base.hh.
| typedef const V& mln::complex_image< D, G, V >::rvalue |
Return type of read-only access.
Definition at line 180 of file mln/core/image/complex_image.hh.
typedef p_complex< D, G > ::site mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::site [inherited] |
Site associated type.
Definition at line 111 of file core/internal/image_base.hh.
| typedef complex_image< D, tag::psite_<G>, tag::value_<V> > mln::complex_image< D, G, V >::skeleton |
Skeleton.
Definition at line 183 of file mln/core/image/complex_image.hh.
typedef mln::value::set<V > mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::t_eligible_values_set [inherited] |
Eligible-value-set associated type.
Definition at line 91 of file core/internal/image_base.hh.
typedef mln::value::set< typename mln::value::super_value<V >::ret > mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::t_values_space [inherited] |
Value space associated type.
Definition at line 98 of file core/internal/image_base.hh.
| typedef V mln::complex_image< D, G, V >::value |
Value associated type.
Reimplemented from mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >.
Definition at line 174 of file mln/core/image/complex_image.hh.
Constructor & Destructor Documentation
| mln::complex_image< D, G, V >::complex_image | ( | ) | [inline] |
Constructors.
Definition at line 276 of file mln/core/image/complex_image.hh.
| mln::complex_image< D, G, V >::complex_image | ( | const p_complex< D, G > & | pc | ) | [inline] |
Definition at line 282 of file mln/core/image/complex_image.hh.
References mln::complex_image< D, G, V >::init_(), and mln::p_complex< D, G >::nfaces_of_dim().
| mln::complex_image< D, G, V >::complex_image | ( | const p_complex< D, G > & | pc, | |
| const metal::vec< D+1, std::vector< V > > & | values | |||
| ) | [inline] |
Definition at line 292 of file mln/core/image/complex_image.hh.
References mln::complex_image< D, G, V >::init_(), and mln::complex_image< D, G, V >::values().
Member Function Documentation
| void mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::destroy | ( | ) | [inherited] |
Detach data from an image (free it if nobody else hold it).
| const p_complex< D, G > & mln::complex_image< D, G, V >::domain | ( | ) | const [inline] |
Accessors.
Return the domain of psites od the image.
Definition at line 343 of file mln/core/image/complex_image.hh.
References mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::data_, and mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::is_valid().
Referenced by mln::init_(), and convert::to_image2d().
| bool mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::has | ( | const psite & | p | ) | const [inherited] |
Test if p belongs to the image domain.
Referenced by mln::make::attachment(), and mln::make::detachment().
| const util::tracked_ptr< internal::data<complex_image< D, G, V > > >& mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::hook_data_ | ( | ) | const [inherited] |
Hook to the image data.
| const void* mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::id_ | ( | ) | const [inherited] |
Give an identifier of this image.
When several image variables designate the same image, they share the same identifier.
| unsigned mln::internal::check::image_fastest_< complex_image< D, G, V > , mln::metal::equal< mln_trait_image_speed(complex_image< D, G, V >), trait::image::speed::fastest >::eval >::index_of_point | ( | const P & | p | ) | const [inherited] |
Give the offset of the site p.
- Parameters:
-
[in] p A site.
- Warning:
- This method is final.
- Precondition:
- The image has to be initialized and to own the point
p.
- Postcondition:
- p == point_at_index(result)
| void mln::complex_image< D, G, V >::init_ | ( | const p_complex< D, G > & | pc, | |
| const metal::vec< D+1, std::vector< V > > & | values | |||
| ) | [inline] |
Initialize an empty image.
Definition at line 302 of file mln/core/image/complex_image.hh.
References mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::data_, and mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::is_valid().
Referenced by mln::complex_image< D, G, V >::complex_image(), and mln::init_().
| bool mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::is_valid | ( | ) | const [inherited] |
Test if this image has been initialized; default impl.
Referenced by mln::complex_image< D, G, V >::domain(), and mln::complex_image< D, G, V >::init_().
| std::size_t mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::nsites | ( | ) | const [inherited] |
Give the number of sites of the image domain.
| complex_image< D, G, V >::rvalue mln::complex_image< D, G, V >::operator() | ( | const complex_psite< D, G > & | p | ) | const [inline] |
Read-only access of face value at point site p.
Definition at line 317 of file mln/core/image/complex_image.hh.
References mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::data_, mln::complex_psite< D, G >::face_id(), and mln::complex_psite< D, G >::n().
| complex_image< D, G, V >::lvalue mln::complex_image< D, G, V >::operator() | ( | const complex_psite< D, G > & | p | ) | [inline] |
Read-write access of face value at point site p.
Definition at line 326 of file mln/core/image/complex_image.hh.
References mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::data_, mln::complex_psite< D, G >::face_id(), and mln::complex_psite< D, G >::n().
| const metal::vec< D+1, std::vector< mlc_unbool(V) > > & mln::complex_image< D, G, V >::values | ( | ) | const [inline] |
Return the array of values associated to the faces.
Definition at line 335 of file mln/core/image/complex_image.hh.
References mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::data_.
Referenced by mln::complex_image< D, G, V >::complex_image().
| const t_eligible_values_set& mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::values_eligible | ( | ) | const [inherited] |
| const t_values_space& mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::values_space | ( | ) | const [inherited] |
Return the value space of the image.
Member Data Documentation
util::tracked_ptr< internal::data<complex_image< D, G, V > > > mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::data_ [protected, inherited] |
Definition at line 163 of file core/internal/image_base.hh.
Referenced by mln::complex_image< D, G, V >::domain(), mln::complex_image< D, G, V >::init_(), mln::complex_image< D, G, V >::operator()(), and mln::complex_image< D, G, V >::values().
const unsigned mln::complex_image< D, G, V >::dim = D [static] |
The dimension of the complex.
Definition at line 170 of file mln/core/image/complex_image.hh.
